Non Coin-Operated Binoculars and Telescopes
Vista scopes makes non coin-operated binoculars and telescopes in both a standard model and an ADA (Wheelchair Accessible) model. We also make non coin-operated specialty models.
Once you decide on a non-coin model, you simply need to choose between magnifications.
Available Models
Model | Style | Magnification | Coin Acceptance |
M10XNC | Binoculars | 10X | Mechanical |
M20XNC | Binoculars | 20X | Mechanical |
M20XNCT | Telescope | 20X | Mechanical |
M35XNCT | Telescope | 35X | Mechanical |
M50XNCT | Telescope | 50X | Mechanical |
Specifications
M10XNC | M20XNC | M20XNCT | M35XNCT | M50XNCT | ||
Optics | ||||||
Magnification | 10x | 20x (Waterproof Optics) |
20x (Waterproof Optics) |
35x (Waterproof Optics) |
50x (Waterproof Optics) |
|
Field of View | 400 feet at 1000 yds |
120 feet at 1000 yds |
110 feet at 1000 yds |
90 feet at 1000 yds | 90 feet at 1000 yds | |
Focus | Auto Focus | Yes - reciprocating | Yes | Yes | Yes | |
Objective Diameter | 50 mm | 60 mm | 60 mm | 60 mm | 60 mm | |
Exit Pupil Aperture | 5 mm | 3 mm | 3 mm | 2.5 mm | 2.5 mm | |
Interpupilliary Distance | 2.5 inches | 2.5 inches | ||||
Long Eye Relief | yes | |||||
Construction | ||||||
Viewing Head | polished aluminum | |||||
Viewing Head Support Arms | stainless steel | |||||
Main Tube | powdercoated aluminum 0.1875 inch wall thickness |
|||||
Base | powdercoated aluminum | |||||
Standing Ring | cast aluminum | |||||
Standing Ring Height from floor |
12 inches | |||||
Dimensions | ||||||
Machine Height | 5ft. 2 in | |||||
Height at Eyepieces | 5ft. 0 in | |||||
Machine Weight | 165 lbs | |||||
Height of Standing Ring | 12 inches | |||||
Diameter of Main tube | 6 inches | |||||
Base Diameter | 28 inches | |||||
Base Options | Yes - we can provide custom flat steel plate bases for certain applications | |||||
Movements | ||||||
Horizontal | tapered roller bearing system - 285 degrees (can be modified on request) | |||||
Vertical | bronze bearing on stainless steel trunnion - +/- 30 degrees | |||||
Other | ||||||
Sign | sign frame holes are pre-drilled and a stainless steel sign frame comes with each unit | |||||
Colors | standard color is textured black with aluminum head. Sand, moss green, blue, green and red are also available. - On request, we can discuss other colors |
|||||
Warranty | ||||||
5 years on all parts |
